Mixing unit 3.5 interchangeable with dumper bucket: Mixing unit (drum capacity 4850 l, concrete yield 3,5 m3) complete with all necessary attachments, hydraulic pumps, motor and hydraulic controls fitted on the chassis
This feature is available only when dumper and mixer attachment are ordered at the same time
Engine:
Perkins 1104 D-44 TA Turbo-Diesel, water- cooled, 4 cylinders.U.E. + U.S.A.: Perkins 854 E-34 TA Turbo-Diesel, water-cooled, 4 cylinders. Rated power KW 83 (111 HP) set at 2.300 rpm
Transmission:
fully hydrostatic Bosch Rexroth with electric inverter. Gear box with mechanic control, two speeds. 4 wheel drive and steering
Axles:
Dana Spicer with oil bath disc brakes and planetary reducers
Speed:
Working speed : 0 to 9 km/h
Road transfer from 0 to 25 km/h
Driving Seat:
Reversible seat with automatic inversion of hydraulic steering circuits. ROPS-FOPS (UNI 11023 – ISO 3471) cab closed on 3 sides
Skip:
Heavy duty rock type. Hydraulic tilting with 2 cylinders
Hydraulic System:
2 indipendent circuits, variable outlet pump for hydrostatic transmission and hydraulic pump for services. Heat exchanger water-oil-air/air type
payload:
Kg. 10.000
Brakes:
Oil bath disc brakes on 4 wheels. Hydraulic parking brake negative on rear axle manually operated
Tyres:
Off road industrial type 16/70-20 14 PR
Steering:
Hydrostatic, “load sensing“ type 3 way steer- ing. Radius: internal 2000 mm. external 3700 mm
Electric System:
12 volt. 120 Ah battery for electric starter and road lighting. Safety battery cut-off
Gradient:
fully loaded 30%
Tanks:
Diesel: 115 liters
Hydraulic oil: 80 litri
Chassis:
Steel profile specially enginereed for off-road operations
Weight:
Empty: 5.800 kg equally distributed on both axles
Safety:
Machine equipped with checking and block valves for maximum safety of the operator
Catalogue:
The machine is equipped with Use and Manteinance and Spare Parts Manuals according to CE regulations
